Lamp Life |
2000hrs |
|
Light Level Adjustment |
N/A |
|
Light Level Sensor |
N/A |
|
Light Source |
D50 or D65, CWF, UVA, CIE A, and one of TL83, TL84, U30, U35 |
|
Total Light Sources |
5 |
|
Humidity |
Rh 0 to 95% max (non-condensing) |
|
Operating Temperature Range |
32°F to 104°F / 0°C to 40°C |
|
Storage Temperature Range |
32°F to 104°F / 0°C to 40°C |
|
Material |
Steel |
|
Unit Color |
Munsell N7 |
|
Viewing Area (length, width, height) |
25 in x 18.5 in x 15 in / 63.5 cm x 47 cm x 38 cm |
|
Dimensions (length, width, height) |
27 in x 21.5 in x 21 in / 68.5 cm x 54.5 cm x 53.5 cm |
|
Weight |
60 lbs / 27 kg |
|
Shipped Weight |
70 lbs / 31.5 kg |
|
Communication Interface |
Touchpad |
|
Instrument Display |
Indicator Light |
|
Languages Supported |
English |
|
Voltage |
100, 115, 127, 230V |
|
Warm Up Time |
3min (flourescent) |
|
Wattage |
65W Max. |
|
Industry Standards |
ISO, ASTM, AATCC, and BSI visual assessment requirements |
|
Calibration |
No |
|
Internal Temperature & Humidity Sensor |
No |
|
Lamp Timer |
Yes |
|
Safety |
ETL Listed |
|
Service Indicator |
Yes |
|
UV Metamerism Index |
Grade C ( AS DEFINED BY CIE 51.2-1999 TECHNICAL REPORT, "A METHOD FOR ASSESSING THE QUALITY OF DAYLIGHT SIMULATORS FOR COLORIMETRY." ) |
|
Visible Metamerism Index |
Grade B ( AS DEFINED BY CIE 51.2-1999 TECHNICAL REPORT, "A METHOD FOR ASSESSING THE QUALITY OF DAYLIGHT SIMULATORS FOR COLORIMETRY." ) |
|
Warranty |
1-2 year |
